1993-2002 Camaro UMI Corner Max Front End Kit, Black 207207-B

Ground Up Part #: UMI-207207-B

Manufacturer Part #: 207207-B

No Vehicle Selected
information

Camaro

(fits 1 model)
No Vehicle Selected
information

Camaro

(fits 1 model)
$4,139.99 (Kit)
closed box

Estimate Shipping

  • cross Not Eligible For Discounting
  • cross Not Eligible For Free Shipping
Part Details Vehicle Fitment Reviews
UMI's Corner Max front end kit is a complete corner carving, autocross and road race solution for the 4th gen 1993-2002 Camaro platform. Corner Max products optimize contact patch with a combination of increased caster and roll center height optimization, along with camber gain and bump steer improvements. This kit features UMI Afco rebound adjustable monotube shocks designed by multi-time SCCA Solo champion Sam Strano. The kit includes caster corrected boxed lower arms as well as adjustable tubular upper a-arms. Together, these arms can achieve up to 9 degrees caster while maintaining factory wheelbase. Also included are bolt-in upper mounts to take the place of the corrosion-prone factory mounts and permit roll center height and camber gain adjustment. The UMI twin tube k-member is optimized with a raised roll center height to provide crisp slalom response and less body roll. A race proven heavy-duty bump steer kit and UMI's popular 35mm tubular sway bar rounds out the package. Expect the UMI Corner Max system to dramatically improve cornering performance while still providing a crisp daily drive worthy experience.
Features:
  • Kit is perfect for auto-x and track day cars also used for street corner carving or daily driving
  • Kit includes Strano tuned rebound adjustable monotube shocks built in USA by Afco as well as Made in USA 850 lb Hypercoils.
  • K-member features UMI's exclusive roll center optimization and instantly trims 25 lbs off the front of the car.
  • A-arm geometry adds caster without affecting wheelbase
  • Upper a-arm mount features three pickup point choices to further optimize roll center and camber gain
  • UMI light weight tubular UMI-2112 sway bar included (35mm)
  • Heavy-duty bump steer kit built specifically for racing use (requires spindle drilling)

Manufacturer Part Number : 207207-B

warning WARNING: Cancer & Reproductive Harm - P65Warnings.ca.gov
Brand
Brand Logo UMI Performance
Additional Information
  • SS396.com Part #: UMI-207207-B
  • Brand: UMI Performance
  • Manufacturer Part #: 207207-B
  • Sold As: Kit
  • Shipping Details: This item ships in multiple oversize boxes.
Vehicle Fitment
Make Model Year Body Style
Chevrolet Camaro 1993 -
Chevrolet Camaro 1994 -
Chevrolet Camaro 1995 -
Chevrolet Camaro 1996 -
Chevrolet Camaro 1997 -
Chevrolet Camaro 1998 -
Chevrolet Camaro 1999 -
Chevrolet Camaro 2000 -
Chevrolet Camaro 2001 -
Chevrolet Camaro 2002 -
Installation Time
Installation Time: Info Unavailable
Installation Difficulty
Installation Difficulty: Info Unavailable
